Manual, Automatical Decoiler Top Hat Cap Roll Forming Machine

Place of Origin : China

Brand Name : TECHWELL

Certification : CE

Model Number : TW-RCM

MOQ : 1 Set

Price : Contact Us

Packaging Details : Standard packing

Delivery Time : 55-65 working days

Payment Terms : 40% T/T in advance, 60% T/T before shipment

Supply Ability : 20 sets

Material Thickness : 0.3-0.7mm

Working Speed : 0-15m/min

Axis Shaft : 75mm

Roller Material : 45# steel

Coil Width : 1250mm

Main Motor Power : 7.5KW

Contact Now


Manual, Automatical Decoiler Top Hat Cap Roll Forming Machine



Main Specifications of Top Hat Cap Roll Forming Machine



  • Material thickness: 0.3-0.7mm
  • Material width: depend on customer’s requirement
  • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
  • Weight Capacity Of Decoiler: 5 Ton
  • Main Motor Power: 5.5 Kw
  • Hydraulic Motor Power: 7.5 Kw
  • Forming Station: approx 15 ( depend on profile drawing )
  • Axis Diameter: ¢ 75mm
  • Working Speed: 0-15 m/min
  • Transporting Type: Chain Transmission
  • Heat Treatment of Cutting Blade: HRC 50-60
  • Type of Cutting: Hydraulic cutting
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand
  • Machine Weight: about 5 Ton



Working Flow

Decoiler --- Fedding Guide --- Roll Forming --- Pressing --- Cut-to-length --- Run out table

Manual, Automatical Decoiler Top Hat Cap Roll Forming Machine


Main Components

  • Decoiler -------------------------------------------------- 1 Unit
  • Feeding guide ------------------------------------------ 1 Unit
  • Main roll forming machine ---------------------------- 1 Unit
  • Hydraulic pressing device ---------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------- 1 Unit
  • Hydraulic Station --------------------------------------- 1 Unit
  • PLC computer control -------------------------------- 1 Unit
  • Output table -------------------------------------------- 1 Unit



Reference Drawings






Manual, Automatical Decoiler Top Hat Cap Roll Forming Machine




Application


Roof ridge cap, ridge cap, ridge tile; ridge valley; ridge flashing; valley flashing; top hat cap, top ridge cap.



Our Advantage

  • Top Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



Machine Pictures




Manual, Automatical Decoiler Top Hat Cap Roll Forming Machine



Factory Pictures

Manual, Automatical Decoiler Top Hat Cap Roll Forming Machine



Introduction of Our Company


Manual, Automatical Decoiler Top Hat Cap Roll Forming Machine



Certificate


Manual, Automatical Decoiler Top Hat Cap Roll Forming Machine



Contact Details

CompanyWuxi Techwell Machinery Co.,Ltd
Websitewww.wxtechwell.com
www.cold-rollformingmachine.com
www.roofrollformingmachine.com
Tel/Fax0086-510-83133431
Mobile/Whatsapp0086-15861597732 (Miss Lemon)
E-Mail/Skypesales@wxtechwell.com
Reference Video Link

https://youtu.be/N8FyrCI_Vsw
